Global manufacture

Our manufacturing partners for electronic assemblies, product manufacture and production test extend through both the UK and the Far East.  We maintain regular contact and review, covering electronics assembly, components, plastic mouldings, castings, precision metal stampings, sheet metal and many more.  Members of YWT Engineering and Technology Ltd are import / export qualified through the International Chamber of Commerce and are able to advise on the optimum trade approach for your business should this be needed.  We maintain our own trusted supply chains and are able to leverage these to supply fully tested products to meet your requirements on a business to business basis, managing the full product life cycle from cradle to grave.  We maintain our own MRP systems and can offer:

• Full product turnkey solutions
• Declaration of Conformity and full legislation compliance
• Import / export documentation
• Trusted freight partners with no hidden costs
• Minimum order quantity and stock profile optimisation
• Identification of trusted global manufacturing partners with associated auditing
• Setup and management of global supply chain partners
• Bill or Materials and obsolescence management
• Single point of communication for order management

Working with our trusted supply chain partners allows us to provide you with the product that you need on time with one point of contact from order placement to delivery.  We manage the supply chain and global manufacture challenges, you receive your products delivered to your chosen destination.

Rotating machinery

We are able to design, develop, review and optimise rotating machinery suited to your application, ranging from a few Watts to many tens of kiloWatts.  Our optimisations depend on your application and product requirements.  Whether designing the complete machine to component level from first principles, identifying a reliable low cost alternative, reviewing your existing technology or working with your team to assess technology options we have in depth design experience with the following ac and electronically commutated topologies:

• Permanent magnet synchronous motors
• Single phase ac asynchronous capacitor run induction motors
• Three phase ac asynchronous induction motors
• Single phase ac asynchronous shaded pole induction motors
• Synchronous motors
• Switched reluctance motors
• Separately excited synchronous motors
• External rotor configurations
• Internal rotor configurations

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.  These range across the interactive spectrum of efficiency, acoustics, vibration, power density, ratings, legislative compliance, environmental influence, reliability, risk and life cycle in application.

Controls

Our experience ranges from system design through to schematic creation, component selection, specification, printed circuit board layout and all stages supporting this.  From analogue and digital design, component level analysis through, system architecture through to embedded solutions and code written in C or assembler, we are able to take products from concept through to volume production.  We take pride in our design for manufacture approach from the start of any project.  Our extensive standards knowledge for EMC and LVD compliance means that we build in critical characteristics from the start.  Whether designing from first principles, identifying a reliable low cost alternative to an existing design, working with obsolescence, reviewing your existing technology or working with your team to assess technology options we have in depth design experience across the following disciplines:

• Schematic design and printed circuit board layout (we use Pulsonix software)
• Analogue and digital circuit design for low cost, low noise and high performance
• Embedded controls and associated software written in C or assembler as required for system performance
• Switch mode power supply design and associated magnetic components
• Open and closed loop stability in both the analogue and digital domain
• Circuit design, filter implementation and board layout for emission and immunity compliance in high performance environments
• Low voltage and high voltage criteria for component selection, implementation and testing
• Functional and component level test requirements and associated design implementations
• Graphic display implementations (LED, LCD and panel)

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.  We are directly supported by many of the major semiconductor manufacturers and are able to call on their support as required to ensure optimal designs are followed through to production.

Power electronics and motor drives

Our power electronics experience covers such diverse fields as power factor correction, inverters for off line lighting and uninterruptible power supplies, hybrid converters, topologies for single phase electronically commutated motors through to multi phase vector controlled motor drives for induction, switch reluctance and permanent magnet synchronous machines.  With systems ranging from a few Watts to tens of kiloWatts designs are optimised for the application and assessed to component level.  Whether designing from first principles, identifying a reliable low cost alternative, reviewing your existing technology or working with your team to assess technology options we have in depth design experience with the following:

• Schematic design and printed circuit board layout for power electronic circuits (using Pulsonix software)
• Circuit design, filter implementation and board layout for emission and immunity compliance in high power envronments
• Open and closed loop stability in both the analogue and digital domain
• Single phase and three phase vector control implementation both analogue and digital domains, including space vector modulation approaches and sensorless algorithms
• AC and DC power converters with associated magnetic and planar magnetic component design
• MOSFET, IGBT and bipolar power stages with associated isolated and non-isolated gate drives
• Power factor correction and sinusoidal waveform control in both the analogue and digital domain
• Measurement circuits and safe probing in the high voltage, high power environment
• Isolated and non-isolated converters

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.  We are directly supported by many of the major semiconductor manufacturers and are able to call on their support as required to ensure optimal designs are followed through to production.

High voltage pulse technology

With experience in the design of equipment related to electric fence energisers, high voltage pulse forming and system fault detection we feel that we are well qualified to design, develop, review and optimise safe systems that incorporate technology suited to the application.  Ranging from fractional Joules to tens of Joules our optimisations depend on the application and product requirements.  This is a rather specialsed area where we have in depth design experience with the following:

• Schematic design and printed circuit board layout for systems operating up to 20 kV (using Pulsonix software)
• Pulse forming techniques and discharge circuits
• Energy quantification and discharge control
• Electromagnetic component design for high voltage applications
• Transmission line theory and associated calculations in high energy pulsed power environments
• Mechanical and electromagnetic layout for pulsed power system function
• Diagnostic techniques, current and voltage measurements in the high voltage, high energy pulsed power environment
• Marx and Marx-like generators
• Discharge and electrical breakdown

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.  In this specialised area we pride ourselves in adopting safe systems of work to ensure reliability and to make sure that any risks are clear and understood.

HVAC

With extensive experience in the design of air moving products and their applications, we are able to develop, review and optimise impeller, volute and system application details that incorporate technology suited to your requirements.  Ranging from a few Watts to many tens of kiloWatts our optimisations depend on your application and product requirements.  In depth knowledge of current legislation allows us to either design from first principles, identify reliable low cost alternatives, review your existing technology or work with your team to assess technology options ranging from ac through to electronically commutated topologies:

• Forward curved impeller characteristics
• Backward curved impeller characteristics
• Flow measurement and control
• Performance characteristics, efficiency and system optimisation
• Acoustic signature and noise reduction
• Vibration sources, transfer characteristics and impact reduction
• Optimal motor technology selection for system operation
• External rotor configurations
• Internal rotor configurations

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.  These range across the interactive spectrum of efficiency, acoustics, vibration, power density, ratings, legislative compliance, environmental influence, reliability, risk and life cycle in application.

Associated applications

This covers the electromechanical aspects of both product design and application.  With extensive experience in the design of air moving products, rotating machinery, high voltage pulsed power detection equipment and their applications, we are able to design, develop, review and optimise plastic mouldings, castings, sheet metal parts, foam mouldings and turned components.  Working with specialist partners in these areas, we design using Solidworks and ensure that partners are actively involved in designs from the outset.  Material selections and choices are made through evaluation of the optimum technical and commercial requirements best suited to the system and application.  Whether designing from first principles, identifying a reliable low cost alternative, reviewing your existing technology or working with your team to assess technology options we are able to offer partnerships covering:

• Plastic injection moulding and associated tooling
• Low pressure injection moulding for encapsulation and environment management
• High pressure aluminium diecasting and associated tooling
• Precision metal stampings, contact components and associated tooling
• Foam mouldings and associated tooling
• Sheet metal, forming and associated cosmetic coatings
• Precision turned metal parts
• Fixings and fasteners
• Bearing selection and loading for reliability

Working from first principles, our approach is to calculate, review, assess, test and demonstrate using theory and best practice, in conjunction with our selected partners, to give you the confidence that solutions are optimal and have known performance boundaries that suit your needs.

Partnerships

To run our business effectively, we value our network of partners that enable us to deliver products and solutions to our customers in time frames that meet our needs.  We are an agile business and choose our partnerships carefully since these need to be able to support our vision in the way that we support our customers; with honesty and integrity.  Our CAD systems and component suppliers are core to this so we are proud to provide links (please see our links page) and to represent them as follows:

• Pulsonix
• Visiativ (Solidworks)

Without our chosen partners, we would not be able to support our customers.  Our priority is to be seen by our customers as their chosen partner.
